  • Bonded laser crystals
  • Bonded laser crystals
Bonded laser crystals Bonded laser crystals

Bonded laser crystals

  • Decrease thermal lens effect
  • Improve efficency and damage threshold
  • Compact size and better beam quality
  • Diffusion Bonding Laser Crystals
    Inquiry Send Email

    Description

    Diffusion Bonding Crystals are crystals consisting of two, three or more parts with different types, Bonding Crystals are often used to decrease thermal lens effect, that is conducive to the stability of lasers and high-power laser operation. This bonding technology in laser applications can not only greatly improve the laser performance and beam quality, but also conducive to the integration of laser systems and access to large-size crystal.

    Following diffusion bonding crystals are available in Jlike Optics:

    Bonding Crytals Types

    Doping Concentration (atm) or Optical Density (cm-1)

    Aperture (mm)

    Length (mm)

    YAG+Nd :YAG

    Nd:0.6~1.2%

    2×2~20×20

    2~200

    YAG+Cr4+ :YAG

    0.6~7

    2×2~20×20

    2~50

    Nd :YAG + Cr4+:YAG

    Nd:0.6~1.2% / 0.6~7

    2×2~20×20

    2~200

    YAG+Nd :YAG+YAG

    Nd:0.6~1.2%

    2×2~20×20

    3~200

    YAG+Nd:YAG+Cr4+:YAG

    Nd:0.6~1.2% / 0.6~7

    2×2~20×20

    3~200

    YAG+Nd:YAG+Cr4+:YAG+YAG

    Nd:0.6~1.2% / 0.6~7

    2×2~20×20

    5~200

    Cr:YAG+Nd:Ce:YAG

    0.6-7/Nd:0.9~1.3% Ce:Nd=1:10

    2x2~10x10

    5~130

    YAG+Cr4+:YAG+Nd:Ce:YAG+YAG

    0.6~7/Nd:0.9~1.3%, Ce:Nd=1:10

    2×2~10×10

    5~130

    YVO4+Nd:YVO4+YVO4

    Nd:0.1~3%

    2x2~10x10

    1~20

    YVO4+Nd:YVO4+YVO4

    Nd:0.1~3%

    Dia.2~10

    3~20

    Other types of custom bonded crystals are available upon customer's request.

    Some diffusion bonding rods modules example as reference

    Diffusion Crystals Modules

    Diffusion Bonding types

    Descriptions

    SHYAG-B-D6.35x105-T20

    Nd:YAG+Cr:YAG

    Nd:YAG D6.35x105mm; HR1064nm

    Cr:YAG T0=20%; PR=40%

    SHYAG-B-D3x50-T40

    Nd:Ce:YAG+Cr:YAG

    Nd:YAG D3x50mm; HR1064nm

    Cr:YAG T0=40%; PR=40%

    SHYAG-B-D3x10-T40

    Nd:YAG+Cr:YAG

    Nd:YAG D3x7.5mm; HR1064nm

    Cr:YAG T0=40%; PR=40%

    SHYAG-B-D3x10-T45

    YAG+Nd:YAG+Cr:YAG

    YAG D3x0.7mm; HR1064nm;

    Nd:YAG D3x7.3mm;

    Cr:YAG T0=45; PR=45%

    Other types of custom bonded crystals are available upon customer's request.

    Crystals, optics and components for laser systems and applications;
    • Scintillation crystals and components for X-ray, nuclear ray detection;
    • SAW crystals and wafers, Sapphire and other crystal and optics products for semiconductor, industrial, medical, scientific and research applications.

    The products are widely used in the laser systems and instruments manufacturing, thermal imaging cameras, X-ray equipments, nuclear ray detecting instruments, Tera Hertz applications, medical and biological equipments, automation and precision instruments in field of industry, defense and security, scientific research and aerospace.
