Ipl lamp

highe temperature sealing

longer service life

Flash stability

High-quality raw materials and quality inspection

Description

The IPL (Intense Pulsed Light) lamps we offer have the following

Generally, a Xenon lamp need to seal in a quartz glass tube of the two metal electrodes to store electrical energy, after a high vacuum tube filled with xenon gas treatment, to output the pulse light pulse discharge of the gas discharge lamp. Xenon Lamp widely used in laser engraving machine, laser welding machine, laser drilling machine, laser beauty machine. We manufacture Xenon Lamp selection of quality UV filter quartz tube as the tube material to high quality density thorium tungsten, barium, cerium tungsten electrode tungsten or xenon lamp electrodes, with a load capacity, high efficiency pump laser beam quality, long life and other characteristics.
According to the current, the lifespan is generally between 300-800 hours.
Due to the loss of gas, the xenon lamp requires periodic replacement, which can guarantee that the machine is running at highest efficiency.

We use high-quality quartz glass tube, the xenon lamp has high efficiency, long life, etc.

1)Applications:

• Hair removal: limbs hair, axillary hair, beard, lip hairs, etc.
• Skin rejuvenation: remove wrinkle, whiten skin, shrink pore, remove acne, etc.
• Speckle removal: freckle, age pigment, sunburn, birthmark, etc.

• Vascular Lesions: telangiectasia, rosacea, spider angiomatas, etc.

• light source for laser equipments. It is the most important consumable of machine. its quality and matching issues affect the performance and quality of laser equipment directly. Nd: YAG pulsed xenon lamp is widely used in laser engraving machine, laser welding machine, laser drilling machine, laser beauty machines. Xenon lamp takes the role of changing the electrical energy into luminous one, the laser power is designed by how to light and how to control the discharge of xenon lamp.

2) Features

· Excellent flash to flash reliability

· High quality manufacturing standards

· Consistent spectral output

· High quality raw materials

· Several lamp connectors are available

· All lamps are tested after production

· Long and consistent lifetime

3)Common Size

OD (mm)	ID (mm)	Arc-length (mm)	Quarts Tube Length(mm)
Φ5	Φ3	35	95
Φ5	Φ3	45	100
Φ5	Φ3	50	113
Φ5	Φ3	55	92
Φ5	Φ3	60	126
Φ5	Φ3	75	147
Φ6	Φ4	58	90
Φ7	Φ5	45	90
Φ7	Φ5	50	90
Φ7	Φ5	50	100
Φ7	Φ5	50	115
Φ7	Φ5	60	125
Φ7	Φ5	65	130
Φ7	Φ5	70	135
Φ7	Φ5	75	140
Φ7	Φ5	95	160
Φ7	Φ5	100	185
Φ8	Φ6	140	210
Φ8	Φ6	150	220
Φ8	Φ6	170	240
Φ9	Φ7	70	136
Φ9	Φ7	80	144
Φ9	Φ7	95	160
Φ9	Φ7	100	190
Φ9	Φ7	140	210
Φ9	Φ7	150	220
Φ9	Φ7	170	240
Φ9	Φ7	180	304
Φ12	Φ9	215	275
